SAMSUNG
超細邊框顯示器
SAMSUNG 大型商用顯示器,以細膩無比的影像品質與均衡鮮明的色彩科技,呈現專業完美的影像。薄型化邊框與簡約時尚的設計,不僅能清楚播放,也能擴充為影像牆,使用上更多樣化,滿足您的需求。


◎極致超薄邊框
SAMSUNG UT系列的極致纖薄邊框,底部和右側僅有2.4mm,面板上方和右側僅有4.3mm (顯示器並排的邊框寬度 6.7mm)。在大型商用顯示器中前所未有的纖薄邊框!影像牆幾乎可以無縫展示精采內容。挑戰大型商用顯示器零接縫視覺效果!


◎曲面影像牆功能
MID46-2 ID Kit 擁有安裝簡易,不僅僅組裝更快速、更便利、更省時,最多可達40度的拼接角度 (Front Folding)(顯示器間最高達40°曲度的顯示能力)讓顯示螢幕組裝型式更多樣,螢幕牆面排列從最多可達5X5的矩形排列、三角排列與突破性的環狀排列,再加上獨家高達178度的可視角面板,Samsung LFD UTn系列創造大型商用螢幕最震撼、最清晰的視覺效果。


◎維護更簡易
為了更方便使用,背板設計成容易解除,不需要從影像牆上拆卸任何顯示器。


◎網路內容管理
460UTn & 460UTn-UD內建PC Windows XP和MagicInfo Pro功能,讓你經由WAN和LAN更輕鬆、快速地更新軟體並擴充使用內容來管理網路。


◎冷卻系統強化
改善了空氣流通系統以增加冷卻強度及元件壽命。

詳細規格 / 尺寸表
型號 460UT 460UTn 460UTn-UD
尺寸 46" 46" 46"
真實解析度 1366 x 768 1366 x 768 1366 x 768
點距 0.7455 x 0.7455 mm 0.7455 x 0.7455 mm 0.7455 x 0.7455 mm
亮度 700 cd/m2 700 cd/m2 700 cd/m2
對比度(Typ./
Dynamic)
3000:1 / 40,000:1 3000:1 / 40,000:1 3000:1 / 40,000:1
反應時間
(G-to-G)
8ms 8ms 8ms
可視角度 (H/V) 178°/178° 178°/178° 178°/178°
色域(CIE1931) 72% 72% 72%
電腦輸入 VGA/DVI/BNC/PC (Support SOG) VGA/DVI/BNC/PC (Support SOG) VGA/DVI/BNC/PC (Support SOG)
影像輸入 CVBS/HDMI/Component CVBS/HDMI/Component CVBS/HDMI/Component
網路 MagicInfo Pro-Extension MagicInfo Pro-Extension MagicInfo Pro-Extension,
Samsung UD
最大耗電功率 260W 330W 330W
待機 2W (Energy Saving On) 5W (Energy Saving On) 5W (Energy Saving On)
電源供應 AC 100 - 240V~ (+/-10%),
50/60 Hz
AC 100 - 240V~ (+/-10%),
50/60 Hz
AC 100 - 240V~ (+/-10%),
50/60 Hz
VESA Mount 600 x 400 mm 600 x 400 mm 600 x 400 mm
操作溫度 10°C – 40°C 10°C – 40°C 10°C – 40°C
濕度 10 – 80% 10 – 80% 10 – 80%
MTBF 50,000 hours 50,000 hours 50,000 hours
Run Time Continuous 24/7 Continuous 24/7 Continuous 24/7
特色 - Lamp Error Detection
- Temperature Sensor
- Built-in Fan
- IR In/Out
- RS232C
- Lamp Error Detection
- Temperature Sensor
- Built-in Fan
- IR In/Out
- RS232C
- Lamp Error Detection
- Temperature Sensor
- Built-in Fan
- IR In/Out
- RS232C
Operating System   Windows XP Embedded Windows XP Embedded
CPU   Athlon x2 Dual-Core 4450e
(2.3GHz)
Athlon x2 Dual-Core 4450e
(2.3GHz)
FDM 4 G 4 G
Memory SEC DDR2 1GB (Single Channel) SEC DDR2 1GB (Single Channel)
MagicInfo Features - Contents Play (Photo, Movie,
Music, Offices, PDF, Flash,
Web Page, Text, Input Sources)
- Contents Scheduler
- MDC via Network
- Diagnosis (Lamp, Temperature,
etc.)
- Network System Information
- Asset Management
- Global Network
- Contents Play (Photo, Movie,
Music, Offices, PDF, Flash,
Web Page, Text, Input Sources)
- Contents Scheduler
- MDC via Network
- Diagnosis (Lamp, Temperature,
etc.)
- Network System Information
- Asset Management
- Global Network
Software Samsung UD Software
不含腳架尺寸
(H x W x D)
40.4" x 22.8" x 5.1" 40.4" x 22.8" x 5.1" 40.4" x 22.8" x 5.1"
含腳架尺寸
(H x W x D)
40.4" x 25.4" x 12.2" 40.4" x 25.4" x 12.2" 40.4" x 25.4" x 12.2"
裝箱尺寸
(H x W x D)
45.2" x 27.8" x 13.0" 45.2" x 27.8" x 13.0" 45.2" x 27.8" x 13.0"
Manuals Quick Setup Guide, Warranty
Card, Application CD
Quick Setup Guide, Warranty
Card, Application CD
Quick Setup Guide, Warranty
Card, Application CD, UD
Software Included
Cables D-Sub, Power Cord D-Sub, Power Cord D-Sub, Power Cord
Others Remote Controller, Batteries Remote Controller, Batteries Remote Controller, Batteries
Speaker N/A N/A N/A
Wall Mount WMN-5770D WMN-5770D WMN-5770D
Vertical Mount WMN-5770D WMN-5770D WMN-5770D
Ceiling Mount CML500D CML500D CML500D
Stand Optional Optional Optional
Emission Standard EMC EMC EMC
RoHS Compliant
Product Recyclability CCFL backlight contains mercury,
please dispose of properl
CCFL backlight contains mercury,
please dispose of properl
CCFL backlight contains mercury,
please dispose of properl
Packaging Recyclability Packing materials recyclable Packing materials recyclable Packing materials recyclable

※ 本網站所提供產品規格內容如有變更,恕不另行通知。實際請以原廠官方最新公告資訊為主。
